Car Wiring Diagrams for Retractable running boards circuit for Ford Expedition IV (2017-2022)

BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM FUSE 89 GRN/BLU WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE HALL EFFECT PWR HOT AT ALL TIMES ILLUMINATION INSTRUMENT PANEL CLUSTER (IPC) LEFT RUNNING BOARD MOTOR ASSEMBLY (UNDER LEFT SIDE OF VEHICLE) LH RB DEPLOY LH RB HALL EFFECT SIG LH RB STOW MS CAN + POWER POWER RUNNING BOARD (PRB) MODULE RED WIRE RH RB DEPLOY RH RB HALL EFFECT SIG RH RB STOW RIGHT RUNNING BOARD MOTOR ASSEMBLY (UNDER RIGHT SIDE OF VEHICLE) SSR RTN SYSTEM VBATT VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/GRN WIRE
