Ford Expedition IV (2017-2022) zero pos Wiring diagram
This page shows the only wiring diagram for the component.zero pos, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram zero pos (1 of 1)
BLK/YEL WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LIFTGATE LATCH/UNLATCH ASSEMBLY
NCA WIRE
PAWL/AJAR SW
POSITION SENSOR
PRIMARY RATCHET
PWR MTR-
RELEASE MTR
RIGHT LIFTGATE DRIVE MOTOR ASSEMBLY (BASE OF RIGHT "D" PILLAR)
SECONDARY RATCHET
SENS POWER
SENS RTN
SENS SIG 1
SENS SIG 2
VIO/BRN WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/RED WIRE
YEL/VIO WIRE
ZERO POS
Go to component -> Power liftgate circuit (2 of 3) -> ZERO POS
