Ford Expedition IV (2017-2022) window patch lane departure warning heater Wiring diagrams

AUTO DIMMING INTERIOR MIRROR BATTERY JUNCTION BOX (BJB) BLK/WHT WIRE BLK/YEL WIRE BODY CONTROL MODULE (BCM) CAN (+) COMPUTER DATA LINES SYSTEM EXPEDITION, NAVIGATOR FUSE 25 GRN/BRN WIRE HOT AT ALL TIMES ILLUMINATED LIFTGATE APPLIQUE LEFT REAR LAMP ASSEMBLY MICRO - NCA WIRE RED WIRE REV REV LPS (FET) REVERSE RIGHT REAR LAMP ASSEMBLY TRANSMISSION CONTROL MODULE (TCM) W/ LANE KEEPING AID W/O LANE KEEPING AID W/O LED W/ LED WHT WIRE WHT/BLU WIRE WINDOW PATCH LANE DEPARTURE WARNING HEATER

BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN/VIO WIRE CAN (+) COMPUTER DATA LINES SYSTEM CRUISE CONTROL MODULE (C-CM) FUSE 36 GRN/ORG WIRE GRY/BLU WIRE HEATER HOT W/ IGNITION RELAY ENERGIZED IMAGE PROCESSING MODULE A (IPMA) INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 2 LANE DEPART NCA WIRE VPWR WINDOW PATCH LANE DEPARTURE WARNING HEATER YEL/GRN WIRE

BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/VIO WIRE CRUISE CONTROL SYSTEM EC+ FUSE 22 GRN/BRN WIRE GRN/ORG WIRE HEATER HOT W/ IGNITION RELAY ENERGIZED LEFT EXTERIOR MIRROR NCA WIRE RAIN SENS LIN RAIN SENS PWR REVERSE VPWR WINDOW PATCH LANE DEPARTURE WARNING HEATER WIPER/WASHER SYSTEM YEL/GRY WIRE YEL/ORG WIRE

AUTO DIMMING INTERIOR MIRROR BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE CARGO LAMP GRN WIRE HANDSFREE LIFTGATE ACTUATION MODULE IMAGE PROCESSING MODULE A (IPMA) INTRUSION/ INCLINATION SENSOR LEFT REAR FOG LAMP LEFT REAR INTERIOR LAMP LEFT REAR LAMP ASSEMBLY LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) LEFT THIRD ROW HEADREST ACTUATOR LEFT VANITY MIRROR LAMP LIFTGATE/ TRUNK MODULE (LTM) LUGGAGE COMPARTMENT POWER OUTLET SOCKET NCA WIRE OVERHEAD CONSOLE PARKING AID MODULE (PAM) POWER FOLD MODULE (PFM) RADIO TRANSCEIVER MODULE (RTM) RAIN SENSOR MODULE REAR DOME LAMP REAR LAMP FADE CONTROL MODULE REAR WINDOW DEFROST GRID RIGHT REAR FOG LAMP RIGHT REAR INTERIOR LAMP RIGHT REAR LAMP ASSEMBLY RIGHT THIRD ROW HEADREST ACTUATOR RIGHT VANITY MIRROR LAMP SECOND ROW FOLDING SEAT SWITCH THIRD ROW FOLDING SEAT SWITCH VIO WIRE WHT WIRE WINDOW PATCH LANE DEPARTURE WARNING HEATER

BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/VIO WIRE EC+ FUSE 22 GRN/BRN WIRE GRN/ORG WIRE HEATER HOT W/ IGNITION RELAY ENERGIZED IMAGE PROCESSING MODULE A (IPMA) LEFT EXTERIOR MIRROR NCA WIRE RAIN SENS LIN RAIN SENS PWR REVERSE VPWR WINDOW PATCH LANE DEPARTURE WARNING HEATER WIPER/ WASHER SYSTEM YEL/GRY WIRE YEL/ORG WIRE

AMBIENT LTG (FET) AUTO DIMMING INTERIOR MIRROR BATTERY ENERGY CONTROL MODULE B (BECMB) BLU/BRN WIRE BLU/GRY WIRE BRN/WHT WIRE CHMSL LP (FET) DRIVE MODE SWITCH ENG LP (FET) FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 11) FROM LIFTGATE RELEASE (FET) (DIAGRAM 7 OF 11) FUEL PUMP ON (FET) FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 34 FUSE 35 FUSE 36 FUSE 37 GEAR SHIFT MODULE (GSM) GRN/ORG WIRE HEADLAMP CONTROL MODULE (HCM) HEATED STEERING WHEEL MODULE (HSWM) IGNITION RELAY IMAGE PROCESSING MODULE A (IPMA) IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR KEYPAD ILLUM (FET) LF DRL LPS (FET) LF FOG LP (FET) LF HIGH BEAM (FET) LF LOW BEAM (FET) LF POS LPS (FET) LF TURN LP (FET) LR STOP/TURN LP (FET) LR TURN LP (FET) MICRO - NCA WIRE PARKING AID MODULE (PAM) PUDDLE LAMP (FET) REAR HEATED SEAT MODULE RED WIRE REV LPS (FET) STOP PARK LPS (FET) USED) VEHICLE DYNAMICS MODULE (VDM) WHT WIRE WINDOW PATCH LANE DEPARTURE WARNING HEATER YEL/VIO WIRE

BLK WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) CAN (+) COMPUTER DATA LINES SYSTEM FUSE 13 GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES I/P MICRO - MTR ORG/ WIRE PARK POWER DISTRIBUTION SYSTEM RAIN SENSOR MODULE REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE) RED WIRE RUN/ ACC (FET) VPWR WHT WIRE WHT/BLU WIRE WINDOW PATCH LANE DEPARTURE WARNING HEATER WINDSHIELD WASHER PUMP WIPER YEL WIRE YEL/GRY WIRE YEL/ORG WIRE
