Ford Expedition IV (2017-2022) shorting bar shorting bar Wiring diagram
This page shows the only wiring diagram for the component.shorting bar shorting bar, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shorting bar shorting bar (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLU WIRE
BLU/WHT WIRE
CASE GROUND
CLOCK- SPRING
COLLAPSIBLE STEERING COLUMN MODULE
COMPUTER DATA LINES SYSTEM
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRONT CRASH SENS FEED
DRV FRONT CRASH SENS RTN
FUSE 58
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT W/ LATCHING POWER POINT RELAY 2 ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT IMPACT SEVERITY SENSOR
NCA WIRE
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS FRONT CRASH SENS FEED
PASS FRONT CRASH SENS RTN
PASS FRONT STEERING 2 FEED
PASS FRONT STEERING 2 RTN
PASS ROW 1 CAN VENT 1 FEED
PASS ROW 1 CAN VENT 1 RTN
RESTRAINTS CONTROL MODULE (RCM)
RIGHT FRONT IMPACT SEVERITY SENSOR
ROW 2 CENTER BUCKLE SW
ROW 2 LEFT BUCKLE SW
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
STEERING COLUMN FEED
STEERING COLUMN RTN
VENT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (1 of 5) -> SHORTING BAR SHORTING BAR
