Ford Expedition IV (2017-2022) rf autopark sns Wiring diagram
This page shows the only wiring diagram for the component.rf autopark sns, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf autopark sns (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (RIGHT KICK PANEL)
BRAKE FLUID LVL SW
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEMAND LP/ BATT SAVE (FET)
DOOR LOCKS, ANTI-THEFT SYSTEMS
ENG LP (FET)
ENGINE CONTROLS SYSTEM
EXPEDITION, NAVIGATOR
FUEL PUMP ON (FET)
FUSE 25
FUSE 76
FUSE B (+)
GRN/RED WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
HOOD AJAR
HORN RELAY (FET) RR OUTER SENS
HORNS SYSTEM
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LF AUTOPARK SNS
LF DRL LPS (FET)
LF FOG LP (FET)
LF HIGH BEAM (FET)
LF INNER SENS
LF LED TURN OUTAGE PARK AID SN PWR FRT (HB)
LF LOW BEAM (FET)
LF OUTER SENS
LF POS LPS (FET)
LF TURN LP (FET)
LIN 03
LIN 06
MICRO -
MICRO BODY CONTROL MODULE (BCM)
NAVIGATION SYSTEM
NAVIGATION SYSTEM POWER DISTRIBUTION SYSTEM
PARK AID IND (FET)
PARK LPS (FET) PARK STOP LP (FET)
POWER DISTRIBUTION SYSTEM
PP RLY RESET (FET)
PP RLY SET (FET)
RED WIRE
RF AUTOPARK SNS
RF DRL LPS (FET)
RF FOG LP (FET)
RF HIGH BEAM (FET)
RF INNER SENS
RF LED TURN OUTAGE ECU DRV (PCM WAKE UP) (FET)
RF LOW BEAM (FET)
RF POS LPS (FET)
RF TURN LP (FET)
RUN/ACC (FET)
SEATS SYSTEM
SENS GND
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
TT PARK RLY (FET)
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WIPER/WASHER SYSTEM
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Body control modules circuit (3 of 3) -> RF AUTOPARK SNS
