Ford Expedition IV (2017-2022) left third row seat lift/fold motor 2 Wiring diagram
This page shows the only wiring diagram for the component.left third row seat lift/fold motor 2, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left third row seat lift/fold motor 2 (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN/YEL WIRE
CENTER SECOND ROW SEAT EASY FOLD MOTOR
CONSOLE)
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HEADREST
HEADREST FOLD/POWER LIFTGATE SWITCH (EXPEDITION)
HEADREST SWITCH
ILLUM
LEFT SECOND ROW SEAT RELEASE EASY ENTRY MOTOR
LEFT THIRD ROW HEADREST ACTUATOR
LEFT THIRD ROW SEAT LIFT/FOLD MOTOR 2
LEFT THIRD ROW SEAT LIFT/FOLD MOTOR 4
LIFTGATE SWITCH
LIFTGATE/TRUNK MODULE (LTM)
OPEN/CLOSE SW
OVERHEAD CONSOLE (NAVIGATOR)
RIGHT SECOND ROW SEAT RELEASE EASY ENTRY MOTOR
RIGHT SECOND ROW SEAT RELEASE EASY ENTRY SWITCH
RIGHT THIRD ROW HEADREST ACTUATOR
RIGHT THIRD ROW SEAT LIFT/FOLD MOTOR 1
RIGHT THIRD ROW SEAT LIFT/FOLD MOTOR 3
SW RELEASE
SWITCH
VIO/BRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power folding seats circuit (2 of 2) -> LEFT THIRD ROW SEAT LIFT/FOLD MOTOR 2
