Ford Expedition IV (2017-2022) left running board motor assembly Wiring diagram
This page shows the only wiring diagram for the component.left running board motor assembly, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left running board motor assembly (1 of 1)
10-WAY
8 WAY
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE PEDAL POSITION (BPP) SWITCH
DRIVER FRONT SEAT AMBIENT LIGHTING LAMP
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
DRIVER SAFETY BELT BUCKLE SWITCH
DRIVER SCUFF PLATE LAMP
DRIVER SEAT MODULE (DSM)
FAMILY ENTERTAINMENT SYSTEM
GRY WIRE
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CONTROL SWITCH
LEFT MULTI-CONTOUR CONTROL PUMP
LEFT RUNNING BOARD MOTOR ASSEMBLY
LEFT SECOND ROW SEAT RELEASE EASY ENTRY SWITCH
LEFT THIRD ROW USB SMART CHARGER
NCA WIRE
PARK ASSIST CAMERA MODULE
POWER RUNNING BOARD (PRB) MODULE
ROOF OPENING PANEL MODULE
TRAILER MODULE (TRM)
USED)
VEHICLE DYNAMIC MODULE (VDM)
W/ MEMORY
W/O MEMORY
Go to component -> Ground distribution circuit (6 of 10) -> LEFT RUNNING BOARD MOTOR ASSEMBLY
