Ford Expedition IV (2017-2022) left exterior mirror camera wiring diagram
This page shows the only wiring diagram for the component.left exterior mirror camera, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left exterior mirror camera wiring diagram (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAMERA SELECT SW
COMPUTER DATA LINES SYSTEM
DC TO DC CONVERTER CONTROL MODULE
FRONT 360 VIDEO +
FRONT PARKING AID CAMERA
FUSE 15
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
HOT W/ RUN/START RELAY ENERGIZED
IGN OUT
IGN SW SIG
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 1
IPMB VIDEO OUT -
LEFT EXTERIOR MIRROR CAMERA
LH VIDEO +
LIFTGATE APPLIQUE
LIN RPA CAM
POWER DISTRIBUTION SYSTEM
PWR
REAR VIDEO -
RH VIDEO +
RIGHT EXTERIOR MIRROR CAMERA
SHIELD
SHIELD LIN RPA CAM
SYNC MODULE (APIM)
VIDEO OUT
VIDEO+
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> All around vision camera circuit -> LEFT EXTERIOR MIRROR CAMERA
