Ford Expedition IV (2017-2022) lane depart Wiring diagram
This page shows the only wiring diagram for the component.lane depart, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane depart (1 of 1)
BLK/VIO WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN/VIO WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (C-CM)
FUSE 36
GRN/ORG WIRE
GRY/BLU WIRE
HEATER
HOT W/ IGNITION RELAY ENERGIZED
IMAGE PROCESSING MODULE A (IPMA)
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 2
LANE DEPART
NCA WIRE
VPWR
WINDOW PATCH LANE DEPARTURE WARNING HEATER
YEL/GRN WIRE
Go to component -> Collision avoidance circuit -> LANE DEPART
