Ford Expedition IV (2017-2022) ign sw sig Wiring diagrams
This page contains all the electrical diagrams for the component. ign sw sig, in which he is found in the car Ford Expedition IV (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
ign sw sig wiring diagram (1 of 5)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAMERA SELECT SW
COMPUTER DATA LINES SYSTEM
DC TO DC CONVERTER CONTROL MODULE
FRONT 360 VIDEO +
FRONT PARKING AID CAMERA
FUSE 15
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
HOT W/ RUN/START RELAY ENERGIZED
IGN OUT
IGN SW SIG
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 1
IPMB VIDEO OUT -
LEFT EXTERIOR MIRROR CAMERA
LH VIDEO +
LIFTGATE APPLIQUE
LIN RPA CAM
POWER DISTRIBUTION SYSTEM
PWR
REAR VIDEO -
RH VIDEO +
RIGHT EXTERIOR MIRROR CAMERA
SHIELD
SHIELD LIN RPA CAM
SYNC MODULE (APIM)
VIDEO OUT
VIDEO+
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> All around vision camera circuit -> IGN SW SIG
ign sw sig wiring diagram (2 of 5)
BATTERY JUNCTION BOX (BJB)
BLIS INDICATOR
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DC TO DC CONVERTER CONTROL MODULE
DRIVER DOOR MODULE (DDM)
FUSE 15
FUSE 25
FUSE 26
GRN/VIO WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
IGN OUT
IGN SW SIG
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
MS CAN +
PASSENGER DOOR MODULE (PDM)
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
VBATT
VIO/ORG WIRE
VPWR
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Blind spot information system circuit -> IGN SW SIG
ign sw sig wiring diagram (3 of 5)
A/D CHANNEL 2
A/D CHANNEL 3
A/D CHANNEL 4
A/D RETURN
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BRN/BLU WIRE
CAN (+)
CLOCKSPRING
CNCL
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (CCM)
DC TO DC CONVERTER CONTROL MODULE
FUSE 15
FUSE 38
FUSE 52
GAP DOWN
GAP UP
GRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
HOT W/ RUN/START RELAY ENERGIZED
IGN SW SIG
LEFT LOWER STEERING WHEEL SWITCH (NAVIGATOR)
LEFT STEERING WHEEL SWITCH (EXPEDITION)
NAVIGATION SYSTEM
NCA WIRE
OFF
OUTPUT SHAFT SPEED (OSS) SENSOR
POWER SPLY INPUT
R/S OUTPUT
RED WIRE
RES+
RES/CNCL
RIGHT STEERING WHEEL SWITCH
SET-
STEERING COLUMN CONTROL MODULE (SCCM)
TRANSMISSION ASSEMBLY
TRANSMISSIONS SYSTEM
TURBINE SHAFT SPEED (TSS) SENSOR
VBATT
VPWR
W/O ADAPTIVE CRUISE CONTROL W/ ADAPTIVE CRUISE CONTROL EXPEDITION NAVIGATOR
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Cruise control circuit (2 of 2) -> IGN SW SIG
ign sw sig wiring diagram (4 of 5)
AUDIO UNIT
BACK LTG (FET)
BLK/VIO WIRE
BLU/BRN WIRE
BRN/BLU WIRE
BSI (FET)
CD CHARGER
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (C-CM)
DC TO DC CONVERTER CONTROL MODULE
DEMAND LP/ BATT SAVE (FET)
ECU DRV (PCM WAKEUP) (FET)
ENG START SIG
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 11)
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 3 OF 11)
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT PARKING AID CAMERA
FUSE 12
FUSE 13
FUSE 33
GATEWAY MODULE
GEAR SHIFT MODULE (GSM)
GRN/RED WIRE
GRN/VIO WIRE
GRY/RED WIRE
HEAD-UP DISPLAY (HUD) MODULE
IGN OUT
IGN SW SIG
ILLUMINATED LIFTGATE APPLIQUE
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
INT LTG (FET)
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
LIFTGATE APPLIQUE
LR STOP POS LP (FET)
NCA WIRE
PARK LPS (FET)
PARK STOP LP (FET)
POWERTRAIN CONTROL MODULE (PCM)
PWR OUT
PWR SPLY INPUT
REAR ENTERTAINMENT MODULE (RETM)
REAR FOG LPS (FET)
RED WIRE
RF DRL LPS (FET)
RF FOG LP (FET)
RF HIGH BEAM (FET)
RF LOW BEAM (FET)
RF POS LPS (FET)
RF TURN LP (FET)
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
RR STOP POS LP (FET)
RR STOP/TURN LP (FET)
RR TURN LP (FET)
STEERING COLUMN CONTROL MODULE (SCCM)
TO FUSE 32 (DIAGRAM 11 OF 11)
VIO/BRN WIRE
WHITE LTG (FET)
WHT WIRE
WHT/BLU WIRE
Go to component -> Power distribution circuit (10 of 11) -> IGN SW SIG
ign sw sig wiring diagram (5 of 5)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
DC TO DC CONVERTER CONTROL MODULE
DC/AC INVERTER MODULE
FUSE 15
GRN/VIO WIRE
HOT W/ RUN/START RELAY ENERGIZED
IGN OUT
IGN SW SIG
LIFTGATE APPLIQUE
LIFTGATE GLASS RELEASE
LIN 04
LIN 06
MICRO -
NCA WIRE
PARK
POWER DISTRIBUTION SYSTEM
REAR VIDEO -
SHIELD
SYNC MODULE (APIM)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO/WHT WIRE
VPWR
WHT/GRN WIRE
Go to component -> Rear camera circuit -> IGN SW SIG
