Ford Expedition IV (2017-2022) evap vapor blocking valve Wiring diagrams
This page contains all the electrical diagrams for the component. evap vapor blocking valve, in which he is found in the car Ford Expedition IV (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram evap vapor blocking valve (1 of 2)
A/C CLUTCH RELAY
AIR CONDITIONING (A/C) COMPRESSOR
CABIN HEATER COOLANT PUMP SENSOR
DIFFERENTIAL CONTROL RELAY
ENGINE COOLING FAN RELAY #1
ENGINE COOLING FAN RELAY #2
ENGINE COOLING FAN RELAY #3
EVAP VAPOR BLOCKING VALVE
EVAPORATE EMISSION (EVAP) CANISTER VENT VALVE
EVAPORATE EMISSION (EVAP) PURGE VALVE
FROM REAR WIPER RELAY (DIAGRAM 3 OF 11)
FUSE 35
FUSE 36
FUSE 37
FUSE 38
GRN WIRE
GRY WIRE
GRY/BLU WIRE
IGNITION COIL ON PLUG 1
IGNITION COIL ON PLUG 2
IGNITION COIL ON PLUG 3
IGNITION COIL ON PLUG 4
IGNITION COIL ON PLUG 5
IGNITION COIL ON PLUG 6
LOWER ACTIVE GRILLE SHUTTER
NCA WIRE
OIL PRESSURE CONTROL SOLENOID
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
TRANSMISSION FLUID WARMER TEMPERATURE CONTROL VALVE
TURBOCHARGER BYPASS VALVE (TCBY)
UPPER ACTIVE GRILLE SHUTTER
VACUUM SOLENOID VALVE (VSV)
VIO WIRE
WHT WIRE
YEL/BLU WIRE
Go to component -> Power distribution circuit (4 of 11) -> EVAP VAPOR BLOCKING VALVE
Wiring diagram evap vapor blocking valve (2 of 2)
AMBIENT AIR TEMPERATURE (AAT) SENSOR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRAKE PEDAL POSITION (BPP) SWITCH
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CACT
EVAP VAPOR BLOCKING VALVE
EVAPORATIVE EMISSION (EVAP) CANISTER VENT VALVE
FUSE 16
FUSE 35
FUSE 36
FUSE 37
FUSE 38
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
PCM POWER RELAY
POWER DISTRIBUTION SYSTEM
SIGRTN
TCBP
TRANSMISSION FLUID WARMER TEMPERATURE CONTROL VALVE
TURBOCHARGER BOOST PRESSURE/ AIR COOLER TEMPERATURE (TCBP/CACT) SENSOR
VACUUM SOLENOID VALVE (VSV)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VREF
WHT WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.5l turbo (2 of 7) -> EVAP VAPOR BLOCKING VALVE
