Ford Expedition IV (2017-2022) drive mode switch Wiring diagram
This page shows the only wiring diagram for the component.drive mode switch, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive mode switch (1 of 1)
AMBIENT LTG (FET)
AUTO DIMMING INTERIOR MIRROR
BATTERY ENERGY CONTROL MODULE B (BECMB)
BLU/BRN WIRE
BLU/GRY WIRE
BRN/WHT WIRE
CHMSL LP (FET)
DRIVE MODE SWITCH
ENG LP (FET)
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 11)
FROM LIFTGATE RELEASE (FET) (DIAGRAM 7 OF 11)
FUEL PUMP ON (FET)
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 34
FUSE 35
FUSE 36
FUSE 37
GEAR SHIFT MODULE (GSM)
GRN/ORG WIRE
HEADLAMP CONTROL MODULE (HCM)
HEATED STEERING WHEEL MODULE (HSWM)
IGNITION RELAY
IMAGE PROCESSING MODULE A (IPMA)
IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR
KEYPAD ILLUM (FET)
LF DRL LPS (FET)
LF FOG LP (FET)
LF HIGH BEAM (FET)
LF LOW BEAM (FET)
LF POS LPS (FET)
LF TURN LP (FET)
LR STOP/TURN LP (FET)
LR TURN LP (FET)
MICRO -
NCA WIRE
PARKING AID MODULE (PAM)
PUDDLE LAMP (FET)
REAR HEATED SEAT MODULE
RED WIRE
REV LPS (FET)
STOP PARK LPS (FET)
USED)
VEHICLE DYNAMICS MODULE (VDM)
WHT WIRE
WINDOW PATCH LANE DEPARTURE WARNING HEATER
YEL/VIO WIRE
Go to component -> Power distribution circuit (8 of 11) -> DRIVE MODE SWITCH
