Ford Expedition IV (2017-2022) dc to dc converter control module Wiring diagram
This page shows the only wiring diagram for the component.dc to dc converter control module, which is found in the car Ford Expedition IV (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dc to dc converter control module (11 of 11)
BLU WIRE
DC TO DC CONVERTER CONTROL MODULE
DRIVER MULTI-CONTOUR SEAT MODULE
DRIVER SEAT MODULE (DSM)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT "C" PILLAR)
MICRO -
MICRO BODY CONTROL MODULE (BCM)
MS CAN +
PARKING AID MODULE
POWERTRAIN CONTROL MODULE (PCM)
REAR DIFFERENTIAL CONTROL MODULE (DCMR)
SYNC MODULE (APIM) (CENTER OF DASH)
TRANSMISSION CONTROL MODULE
VIO/ORG WIRE
W/ CENTER CONSOLE W/O CENTER CONSOLE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WIRELESS ACCESSORY CHARGING MODULE
Go to component -> Computer data lines circuit (2 of 4) -> DC TO DC CONVERTER CONTROL MODULE
