Shift interlock circuit, with column shift for Ford Expedition III (2006-2014)
Shift interlock circuit, with column shift
AUTOMATIC TRANSMISSION (RIGHT REAR OF TRANSMISSION)
BATTERY JUNCTION BOX (BJB) (CENTER FRONT OF ENGINE COMPT)
BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL SUPPORT)
BRAKE SHIFT INTERLOCK (EXPEDITION: STEERING COMPUTER DATA LINES SYSTEM COLUMN)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN RUN OR START SMART JUNCTION BOX (SJB) FUSE (BEHIND RIGHT KICK PANEL)
HS CAN+
INSTRUMENT CLUSTER (IC)
MS MS CAN CAN BPP BSI (FET)
OUT OF IN PARK PARK
PK DET
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
TR-P
VBAT CTRL
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL/GRY WIRE
