Driver power seat circuit for Ford Expedition III (2006-2014)
Driver power seat circuit
7 12 5 1 6-WAY POWER SEAT 10-WAY POWER SEAT
BACK
BASE
BLK WIRE
BLU WIRE
BRN WIRE
DOWN
DOWN OUT
DRIVER SEAT FRONT HEIGHT MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT LUMBAR MOTOR (10-WAY POWER SEAT)
DRIVER SEAT REAR HEIGHT MOTOR
DRIVER SEAT RECLINER MOTOR (10-WAY POWER SEAT)
FRONT
GRN WIRE
GRY WIRE
LEFT SEAT CONTROL
LUMBAR
ORG/ WIRE
REAR
RECLINE
RED WIRE
SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
