Ford Expedition III (2006-2014) puddle lamp ec+ Wiring diagram
This page shows the only wiring diagram for the component.puddle lamp ec+, which is found in the car Ford Expedition III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram puddle lamp ec+ (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DEFOGGER SYSTEM
DOWN RIGHT UP
EC+
EXTERIOR REAR VIEW MIRROR SWITCH
FOLD IN/ FOLD OUT
FUSE 12
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT
LEFT DOWN
LEFT HEATED MIRROR
LEFT RIGHT
LEFT SELECT RIGHT MIRROR SWITCH
LEFT SIDE EXTERIOR REAR VIEW MIRROR
LEFT/RIGHT MOTOR
MEMORY SET SWITCH
MIRRORS SYSTEM
NCA WIRE
PUDDLE LAMP EC+
RIGHT
SMART JUNCTION BOX (SJB) (BEHIND RIGHT KICK PANEL)
TURN SIGNAL
UP/DN
UP/DN MOTOR
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> PUDDLE LAMP EC+
