Ford Expedition III (2006-2014) dary sw Wiring diagram
This page shows the only wiring diagram for the component.dary sw, which is found in the car Ford Expedition III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dary sw (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 GND CINCH
BATTERY JUNCTION
BLK/GRY WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
CHIME- SENSOR SIG 1 SENSOR SIG 2
CINCH
CLOSE
CLUTCH
CLUTCH VBATT
COMPUTER DATA LINES SYSTEM
CONSOLE OPEN/ CLOSE SW SECTOR GEAR OPEN SW
CONTROL
DARY SW
DETENT
DOOR LOCKS SYSTEM
FUSE 14
FUSE 17
FUSE 36 BOX (BJB) (CENTER FRONT OF ENGINE COMPARTMENT)
GLASS AJAR SW
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HANDLE SW MS CAN+ MS CAN-
HOT AT ALL TIMES
LEFT LIFTGATE PINCH STRIP (LEFT REAR QUARTER PANEL)
LIFTGATE LATCH/UNLATCH ASSEMBLY
LIFTGATE MOTOR/CLUTCH
LIFTGATE REAR CONTROL SWITCH
LIFTGATE REL (FET)
LIFTGATE/TRUNK MODULE (LEFT SIDE OF CARGO AREA, BEHIND TRIM)
POSITION SENSOR
POWER LIFTGATE CHIME (LEFT REAR CORNER OF VEHICLE)
POWER LIFTGATE/ TRACTION CONTROL/ HAZARD SWITCH
PRIMARY
RIGHT LIFTGATE PINCH STRIP (RIGHT REAR QUARTER PANEL)
SECON-
SENS PWR
SENS RTN
SMART JUNCTION BOX (SJB) (BEHIND RIGHT KICK PANEL)
UNCINCH
UNCINCH VBATT MOTOR OPEN MOTOR CLOSE
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Trunk release circuit -> DARY SW
