Ford Expedition III (2006-2014) ctrl vbat Wiring diagram
This page shows the only wiring diagram for the component.ctrl vbat, which is found in the car Ford Expedition III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ctrl vbat (1 of 1)
AUTOMATIC TRANSMISSION (RIGHT REAR OF TRANSMISSION)
BATTERY JUNCTION BOX (BJB) (CENTER FRONT OF ENGINE COMPT)
BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/GRN WIRE
BSI (FET)
COMPUTER DATA LINES SYSTEM
CTRL VBAT
FLOOR SHIFTER (UNDER CENTER CONSOLE)
FUSE
FUSE 43
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HS CAN + HS CAN -
ILLUM
KEY RELEASE INTERLOCK ACTUATOR (STEERING COLUMN)
PARK INTERLOCK SWITCH
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
SMART MS MS JUNCTION CAN CAN BOX (SJB) BPP (BEHIND RIGHT KICK PANEL)
TR-P
TRANSMISSION CONTROL SWITCH
TRANSMISSIONS SYSTEM
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL/GRY WIRE
Go to component -> Shift interlock circuit, with floor shift -> CTRL VBAT
