Ford Expedition III (2006-2014) ctrl ctrl ctrl wiring diagram
This page shows the only wiring diagram for the component.ctrl ctrl ctrl, which is found in the car Ford Expedition III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ctrl ctrl ctrl wiring diagram (1 of 1)
BATTERY SAVER RELAY
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
CARGO LAMP
CTRL CTRL CTRL
DEFEAT
DF DOOR AJAR
DIM SW GND
DIMMER SW
DOME DEFEAT
DOME LP
DR DOOR AJAR
DRIVER SIDE REAR DOOR AJAR
FRONT INTERIOR/MAP LAMPS ASSEMBLY
FUSE
GLOVE BOX LAMP)
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOMELINK MODULE
HOT AT ALL TIMES
ILLUMINATION DIMMER
INTERIOR LIGHTING (FET)
LEFT FRONT DOOR AJAR SWITCH (REAR OF DRIVER'S DOOR)
LEFT SIDE EXTERIOR REAR VIEW MIRROR
LEFT SIDE RAIL LAMP
LEFT VANITY MIRROR LAMP
NCA WIRE
OFF DOME
OFF DOME DEFEAT
PASSENGER SIDE REAR DOOR AJAR SWITCH (REAR OF RIGHT
PASSENGER'S DOOR
PF DOOR AJAR
PR DOOR AJAR
PUDDLE LAMP
PUDDLE LAMP (FET)
REAR DOOR)
REMOTE START CONNECTOR (IF EQUIPPED)
RIGHT FRONT DOOR AJAR SWITCH (REAR OF FRONT
RIGHT SIDE EXTERIOR REAR VIEW MIRROR
RIGHT SIDE RAIL LAMP
RIGHT VANITY MIRROR LAMP
SMART JUNCTION BOX (SJB)
SWITCH (REAR OF LEFT REAR DOOR)
VIO WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit -> CTRL CTRL CTRL
