Ford Expedition III (2006-2014) ac_a Wiring diagram
This page shows the only wiring diagram for the component.ac_a, which is found in the car Ford Expedition III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ac_a (1 of 1)
1 2 3 4 5 6 LED+
A/C OUTLET (REAR OF CONSOLE)
AC_A
AC_B LED_GND
AUDIO CONTROL MODULE (ACM)
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BOX (BJB) (CENTER FRONT OF ENGINE COMPT)
BRN/YEL WIRE
CONNECTOR (IF EQUIPPED)
DC/AC INVERTER MODULE (BELOW STEERING COLUMN)
FROM FUSE 17 (DIAGRAM 3 OF 5)
FROM FUSE 29 (DIAGRAM 2 OF 5)
FROM FUSE 41 (DIAGRAM 3 OF 5)
FROM IGNITION SWITCH (DIAGRAM 4 OF 5)
FRONT WIPER MOTOR RELAY
FUSE
FUSE 27
FUSE 27 FUSE 33
FUSE 28
FUSE 42 FUSE 44
FUSE 43 RUN/ ACCY
FUSE 45
GRN/RED WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
KEY IN IGNITION
KEY RELEASE INTERLOCK ACTUATOR (W/ FLOOR SHIFTER)
LOCK
MICRO -
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
ORG/WHT WIRE
POWERTRAIN CONTROL MODULE (PCM)
RAIN REAR SENSOR WIPER MODULE MOTOR (IF EQUIPPED) ASSEMBLY
REAR VIEW CAMERA DISPLAY MIRROR (IF EQUIPPED)
RED WIRE
REMOTE +
RUN WIRE
RUN/
SMART JUNCTION BOX (SJB) (BEHIND RIGHT KICK PANEL)
STARTER RELAY
TO RUN/ START RELAY (DIAGRAM 1 OF 5)
TRANSFER CASE CONTROL MODULE (TCCM) IGNITION SWITCH
VBATT
VIO/GRN WIRE
VPWR
W/ REMOTE
W/O REAR VIDEO CAMERA W/ REAR VIDEO CAMERA
WHT WIRE
WHT/ VIO WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (4 of 5) -> AC_A
