Ford Expedition III (2006-2014) 52 31 vref acpt wiring diagram
This page shows the only wiring diagram for the component.52 31 vref acpt, which is found in the car Ford Expedition III (2006-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
52 31 vref acpt wiring diagram (1 of 1)
30 32 CHT SIGRTN
52 31 VREF ACPT
A/C CLUTCH RELAY
A/C PRESSURE TRANSDUCER SENSOR (RIGHT FRONT OF ENGINE COMPT)
ACCR
BATTERY JUNCTION BOX (BJB) (CENTER FRONT OF ENGINE COMPT)
BLK/GRY WIRE
BLU/GRY WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CYLINDER HEAD TEMPERATURE SENSOR (RIGHT REAR OF ENGINE)
ENGINE CONTROL SYSTEM
FUSE 30
GRN/WHT WIRE
GRY BLK/ WIRE
GRY WIRE
HFC
HOT AT ALL TIMES
HS CAN+
LFC
PCMRC
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
SIGNAL RETURN
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, without auxiliary climate control (3 of 4) -> 52 31 VREF ACPT
