Ford Expedition II (2002-2006) Charging circuit

BLK WIRE BLK/ORG WIRE BRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL) CHARGE INDICATOR FUSE 34 FUSIBLE LINK A (12 GA- FUSIBLE LINK B (12 GA- FUSIBLE LINK C (18 GA- GENERATOR (AT TOP FRONT OF ENGINE) GRY WIRE HOT IN START OR RUN INSTRUMENT CLUSTER LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE TAN WIRE TAN/LT GRN WIRE
