Ford Expedition II (2002-2006) up left/right mirror select switch Wiring diagram
This page shows the only wiring diagram for the component.up left/right mirror select switch, which is found in the car Ford Expedition II (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up left/right mirror select switch (1 of 1)
BLK WIRE
BLK/LT BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DIRECT- TIONAL SWITCH
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/ORG WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DLC
DRIVER SEAT MODULE (UNDER DRIVER'S SEAT)
EXTERIOR REAR VIEW MIRROR SWITCH
FOLD IN/ FOLD OUT
FOLD OUT
FOLD-IN
FUSE 3
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT HEATED MIRROR
LEFT RIGHT
LEFT/RIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
ORG/LT GRN WIRE
PNK WIRE
PNK/ORG WIRE
PUDDLE LAMP LEFT EXTERIOR REAR VIEW MIRROR (AT LEFT REAR VIEW MIRROR)
PUDDLE LAMP RIGHT EXTERIOR REAR VIEW MIRROR (AT RIGHT REAR VIEW MIRROR)
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT HEATED MIRROR
TURN SIGNAL
UP LEFT/RIGHT MIRROR SELECT SWITCH
UP/DN
UP/DN MOTOR
UP/DOWN MOTOR
VIO WIRE
VIO/LT GRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/PNK WIRE
YEL/BLK WIRE
YEL/LT BLU WIRE
YEL/RED WIRE
Go to component: -> Memory mirrors circuit, with power folding mirrors -> UP LEFT/RIGHT MIRROR SELECT SWITCH
