Ford Expedition II (2002-2006) right mirror select Wiring diagram
This page shows the only wiring diagram for the component.right mirror select, which is found in the car Ford Expedition II (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right mirror select (1 of 1)
BLK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL)
DEFOGGER SYSTEM
DK BLU WIRE
DK DK
DK GRN WIRE
DOWN
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
GRN WIRE
HEATER
HOT AT ALL TIMES
LEFT
LEFT EXTERIOR REAR VIEW MIRROR
LEFT MIRROR SELECT
LEFT/RIGHT
LEFT/RIGHT UP/DOWN RIGHT EXTERIOR REAR VIEW MIRROR
LT BLU WIRE
NCA WIRE
ORG/LT GRN WIRE
PUDDLE LAMP
PUDDLE LAMP HEATER
RED WIRE
RIGHT
RIGHT MIRROR SELECT
UP/DOWN
VIO WIRE
YEL WIRE
Go to component: -> Power mirrors circuit -> RIGHT MIRROR SELECT
