Ford Expedition II (2002-2006) right front door ajar switch Wiring diagram
This page shows the only wiring diagram for the component.right front door ajar switch, which is found in the car Ford Expedition II (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door ajar switch (1 of 1)
BLK WIRE
DVD PLAYER
DVD PLAYER LEFT SIDE RAIL LAMP
EXPEDITION, NAVIGATOR
FRONT AUXILIARY FUNCTION SELECTOR SWITCH ASSEMBLY
LEFT FRONT MAP READING LAMP
LEFT REAR THIRD ROW FOLDING SEAT SWITCH
LEFT VANITY MIRROR LAMP
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSENGER SIDE CLIMATE CONTROLLED SEAT MODULE
PASSENGER SIDE REAR DOOR AJAR SWITCH RIGHT FRONT LUMBAR ADJUST SWITCH
POWER LIFTGATE OPEN/CLOSE SWITCH
POWER QUARTER WINDOW SWITCH
QUARTER WINDOW CLOSE RELAY
QUARTER WINDOW OPEN RELAY
RADIO
RADIO, AMPLIFIER
REAR BLEND DOOR ACTUATOR
REAR BLOWER MOTOR RELAY
REAR INTEGRATED CONTROL PANEL (RICP)
REAR POWER POINT RIGHT REAR PARK/STOP/ TURN LAMP
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT FRONT DOOR AJAR SWITCH
RIGHT FRONT MAP READING LAMP
RIGHT POWER SEAT SWITCH
RIGHT REAR THIRD ROW FOLDING SEAT SWITCH
RIGHT REAR WINDOW ADJUST SWITCH
RIGHT SIDE RAIL LAMP CARGO LAMP
RIGHT VANITY MIRROR LAMP
ROOF OPENING PANEL MODULE
ROOF OPENING PANEL SWITCH
SUBWOOFER AMPLIFIER
W/ REAR INTEGRATED CONTROL PANEL (RICP), W/ CD CHANGER
W/O REAR INTEGRATED CONTROL PANEL (RICP), W/O CD CHANGER
Go to component: -> Ground distribution circuit (4 of 4) -> RIGHT FRONT DOOR AJAR SWITCH
