Ford Expedition II (2002-2006) power liftgate open/close switch Wiring diagrams

BLK WIRE DVD PLAYER DVD PLAYER LEFT SIDE RAIL LAMP EXPEDITION, NAVIGATOR FRONT AUXILIARY FUNCTION SELECTOR SWITCH ASSEMBLY LEFT FRONT MAP READING LAMP LEFT REAR THIRD ROW FOLDING SEAT SWITCH LEFT VANITY MIRROR LAMP LT GRN WIRE NCA WIRE ORG/ WIRE PASSENGER SIDE CLIMATE CONTROLLED SEAT MODULE PASSENGER SIDE REAR DOOR AJAR SWITCH RIGHT FRONT LUMBAR ADJUST SWITCH POWER LIFTGATE OPEN/CLOSE SWITCH POWER QUARTER WINDOW SWITCH QUARTER WINDOW CLOSE RELAY QUARTER WINDOW OPEN RELAY RADIO RADIO, AMPLIFIER REAR BLEND DOOR ACTUATOR REAR BLOWER MOTOR RELAY REAR INTEGRATED CONTROL PANEL (RICP) REAR POWER POINT RIGHT REAR PARK/STOP/ TURN LAMP RIGHT EXTERIOR REAR VIEW MIRROR RIGHT FRONT DOOR AJAR SWITCH RIGHT FRONT MAP READING LAMP RIGHT POWER SEAT SWITCH RIGHT REAR THIRD ROW FOLDING SEAT SWITCH RIGHT REAR WINDOW ADJUST SWITCH RIGHT SIDE RAIL LAMP CARGO LAMP RIGHT VANITY MIRROR LAMP ROOF OPENING PANEL MODULE ROOF OPENING PANEL SWITCH SUBWOOFER AMPLIFIER W/ REAR INTEGRATED CONTROL PANEL (RICP), W/ CD CHANGER W/O REAR INTEGRATED CONTROL PANEL (RICP), W/O CD CHANGER

1 2 3 4 GND PWR GND PWR 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 UPB BUS 4 3 2 1 GND PWR 4 3 2 1 PWR PWR GND VBATT BLK WIRE BRN WIRE BRN/LT BLU WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL) FUSE 110 COMPUTER DATA LINES SYSTEM DEPLOYED SENSOR DK GRN WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE FLOOR SHIFTER FUSE 105 FUSE 5 GND VPWR GRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT LIFTGATE OBSTACLE DETECTION STRIP (AT LOWER LEFT SIDE OF CARGO AREA) LIFTGATE CHIME MODULE LIFTGATE CINCHING MOTOR (IN RIGHT SIDE OF LIFTGATE) LIFTGATE FORK BOLT/DETENT SWITCH (AT CENTER BOTTOM OF LIFTGATE) LIFTGATE GLASS ACTUATOR (IN LIFTGATE) LIFTGATE HOME POSITION SWITCH (IN RIGHT SIDE OF LIFTGATE) LIFTGATE UNLATCH MOTOR (IN RIGHT SIDE OF LIFTGATE) LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/RED WIRE LT GRN/VIO WIRE MICROPROCESSOR MOTOR NCA WIRE OPTICAL SENSOR LEFT LIFTGATE DRIVE MOTOR ASSEMBLY (AT REAR OF ROOF) ORG/LT BLU WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE POWER LIFTGATE OPEN/CLOSE SWITCH RED WIRE RED/LT BLU WIRE RED/LT GRN WIRE RED/WHT WIRE RIGHT LIFTGATE DRIVE MOTOR ASSEMBLY (AT REAR OF ROOF) RIGHT LIFTGATE OBSTACLE DETECTION STRIP (AT LOWER RIGHT SIDE OF CARGO AREA) SHIFT INTERLOCK SYSTEM SIG RTN STOWED SENSOR TAN/LT BLU WIRE VBATT VEHICLE SECURITY MODULE (VSM) (UNDER RIGHT SIDE OF DASH) VIO WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR VPWR VPWR GND VPWR +/- VREF PWR VREF VREF VREF VREF VREF VREF VBATT VREF W/ POWER FOLDING SEATS WHT WIRE WHT/PNK WIRE WHT/VIO WIRE WHT/YEL WIRE WIPER/ WASHER SYSTEM YEL WIRE
