Ford Expedition II (2002-2006) differential pressure feedback egr sensor Wiring diagram
This page shows the only wiring diagram for the component.differential pressure feedback egr sensor, which is found in the car Ford Expedition II (2002-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram differential pressure feedback egr sensor (1 of 1)
AIR SUSPENSION MODULE, BRAKE SHIFT INTERLOCK, ELECTRONIC COMPASS
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
DIFFERENTIAL PRESSURE FEEDBACK EGR SENSOR
ENGINE CONTROLS SYSTEM
FOUR WHEEL DRIVE CONTROL MODULE (AT LEFT "P" PILLAR)
FUSE 28 FUSE 27
FUSE 32
FUSE 34
GROUND
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATED OXYGEN SENSORS, TURBINE SHAFT SPEED SENSOR, IDLE AIR CONTROL MODULE
HOT AT ALL TIMES
HOT IN RUN OR START
IAT INPUT
INTAKE AIR TEMPERATURE (IAT) SENSOR (IN INTAKE SYSTEM)
LT BLU/RED WIRE
LT BLU/YEL WIRE
MAF OUTPUT
MAF SIG RTN
MASS AIRFLOW (MAF) SENSOR (IN INTAKE SYSTEM)
NCA WIRE
OD CANCEL SW
OVERDRIVE CANCEL SWITCH
PCM POWER DIODE
PCM POWER RELAY
PNK/ORG WIRE
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF FIREWALL)
POWERTRAIN CONTROL MODULE, FUEL INJECTORS
RED WIRE
TAN/LT BLU WIRE
TAN/WHT WIRE
THROTTLE POSITION (TP) SENSOR (ON THROTTLE BODY)
TPS SIGNAL
VIO/WHT WIRE
