Shift interlock circuit for Ford Expedition I (1996-2002)
Shift interlock circuit
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BRAKE PEDAL POSITION(BPP) SWITCH (UNDER LEFT SIDE OF DASH)
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
FUSE 15
FUSE 6
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN
INSTRUMENT CLUSTER (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
PARK BRAKE SWITCH (RIGHT SIDE OF PARK BRAKE LEVER)
PARKING BRAKE RELEASE DIODE
PARKING BRAKE RELEASE SOLENOID (BEHIND LEFT SIDE OF DASH)
PARKING BRAKE RELEASE SWITCH (BEHIND LEFT SIDE OF DASH)
RED WIRE
RED/LT GRN WIRE
SHIFT LOCK ACTUATOR (IN STEERING COLUMN)
SOLID STATE
W/O PARKING BRAKE RELEASE
W/PARKING BRAKE RELEASE
WHT/YEL WIRE
YEL WIRE
