Power door lock circuit for Ford Expedition I (1996-2002)
Power door lock circuit
ALL LOCK RELAY
ALL UNLOCK RELAY
BATTERY JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPT)
BLK WIRE
DRIVER'S UNLOCK RELAY
FUSE 8
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR
LEFT FRONT POWER DOOR LOCK SWITCH
LIFGATE DOOR LOCK ACTUATOR
LOCK
LOCK RELAY BLOCK (BEHIND RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PNK/LT GRN WIRE
PNK/ORG WIRE
PNK/YEL WIRE
PPL
PPL/LT BLU WIRE
RED WIRE
RED/ORG WIRE
REMOTE ANTI-THEFT PERSONALITY MODULE (BEHIND LEFT SIDE OF DASH)
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT POWER DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
UNLOCK
WHT WIRE
YEL WIRE
