Electronic power steering circuit, with air suspension for Ford Expedition I (1996-2002)
Electronic power steering circuit, with air suspension
2 3 4 ROTATION RATE INPUT VEHICLE SIGNAL INPUT IGNITION
AIR SUSPENSION/ EVO STEERING MODULE (BEHIND CENTER OF DASH)
BLK WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BRN WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
ENGINE CONTROL SYSTEM
EVO ACT OUTPUT
EVO ACTUATOR (LEFT SIDE OF ENGINE COMPT)
FUSE 6
GENERIC ELECTRONIC MODULE
GROUND
GRY/BLK WIRE
GRY/YEL WIRE
HOT IN RUN
NCA WIRE
ORG/ WIRE
RED WIRE
RED/YEL WIRE
ROTATION RATE INPUT
SPEED CONTROL SERVO (LEFT SIDE OF ENGINE COMPARTMENT)
STEERING WHEEL ROTATION SENSOR (BEHIND STEERING WHEEL, IN DASH)
YEL WIRE
