Body computer circuits for Ford Expedition I (1996-2002)

ACCESSORY DELAY RELAY ACCESSORY DELAY RELAY CTRL HEATED GRID RELAY CTRL IGNITION (ACC/RUN) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BATTERY SAVER RELAY BLK WIRE BLK/LT BLU WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) CIRCUIT BREAKER FUSE 14 FUSE 15 FUSE 20 FUSE 6 FUSE 8 GENERIC ELECTRONIC MODULE (GEM) GRY WIRE GRY/BLK WIRE HEATED GRID RELAY HOT AT ALL TIMES HOT IN HOT IN RUN OR ACC INTERIOR LAMP RELAY LT BLU WIRE LT BLU/BLK WIRE LT GRN/ORG WIRE ONE-TOUCH DOWN RELAY ORG/LT GRN WIRE ORG/WHT WIRE PNK/ORG WIRE POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM RED WIRE RUN WIRE SOUND SYSTEMS ENGINE CONTROLS SYSTEM ELECTRONIC SUSPENSION SYSTEM TAN/LT BLU WIRE TRANSMISSIONS SYSTEM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ABS ACTIVE IN AIR SUSPENSION OUT TRANSFER CASE RETURN BRAKE PEDAL POSITION SWITCH ANTI-LOCK BRAKES SYSTEM (ABS CONTROL MODULE) ANTI-THEFT SYSTEM (RAP MODULE) BLK WIRE BLK/LT BLU WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE DEFOGGER SYSTEM (REAR DEFOGGER SWITCH) DK BLU WIRE DK BLU/ORG WIRE DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DOOR AJAR OUT GENERIC ELECTRONIC MODULE (GEM) (BEHIND LEFT SIDE OF DASH) GRY/LT BLU WIRE LOW WASHER FLUID OUT REAR WASHER PUMP RELAY OUT WASHER FLUID LEVEL SWITCH IN LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/WHT WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE ORG/WHT WIRE PNK/BLK WIRE PNK/YEL WIRE REAR SHAFT SPEED SENSOR IN FRONT SHAFT SPEED SENSOR IN REAR WIPER SWITCH IN RED/LT GRN WIRE RED/WHT WIRE TAN WIRE TAN/RED WIRE TAN/YEL WIRE TRANSMISSION CONTROLS SYSTEM (TRANSFER CASE ASSEMBLY) VIO/YEL WIRE WHT WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE WIPER/WASHER SYSTEM (MULTI-FUNCTION SWITCH) YEL/LT BLU WIRE YEL/WHT WIRE
