Passive anti-theft circuit for Ford Expedition I (1996-2002)
Passive anti-theft circuit
"ANTI-THEFT" INDICATOR
BLK WIRE
BLK/LT BLU WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE 30
FUSE 6
GRY WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT IN
HOT IN RUN OR START
INSTRUMENT CLUSTER
LT BLU WIRE
LT GRN WIRE
PASSIVE ANTI- THEFT SYSTEM (PATS) TRANS- CEIVER MODULE (BEHIND CENTER OF DASH)
PNK/LT BLU WIRE
RED WIRE
RED/LT GRN WIRE
RUN WIRE
TAN/ORG WIRE
WHT/LT GRN WIRE
YEL WIRE
