Ford Expedition I (1996-2002) xlt only Wiring diagrams
This page contains all the electrical diagrams for the component. xlt only, in which he is found in the car Ford Expedition I (1996-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram xlt only (1 of 2)
18 19 7 9 PNK WIRE
BATTERY JUNCTION BOX FUSE 15
BATTERY SAVER INPUT
BATTERY SAVER RELAY
BLK WIRE
BLK/LT BLU WIRE
CENTRAL JUNCTION BOX
DOOR
ENGINE COMPARTMENT LAMP
FRONT INTERIOR/ MAP LAMP ASSEMBLY
FUSE 14
GENERIC ELECTRONIC MODULE (GEM)
GLOVE COMPARTMENT LAMP
GRN WIRE
HOT AT ALL TIMES
INTERIOR LAMP MAP LAMPS
INTERIOR LAMP RELAY
INTERIOR LAMP RELAY INPUT
INTERIOR LAMP SWITCH
LEFT DOOR COURTESY LAMP
LEFT INTERIOR/ MAP LAMP
LEFT MAP LAMP SWITCH
LEFT RUNNING BOARD LAMP
LEFT SIDE RAIL LAMP
LEFT VANITY LAMP
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
LT GRN/PPL WIRE
MAIN LIGHT SWITCH
MAP LAMPS
NCA WIRE
OFF
OFF ON
ON OFF
ORG/ WIRE
ORG/LT GRN WIRE
OVERHEAD TRIP COMPUTER (W/ MINI CONSOLE)
PNK WIRE
REAR CARGO LAMP
RED WIRE
RIGHT DOOR COURTESY LAMP
RIGHT INTERIOR/ MAP LAMP
RIGHT MAP LAMP SWITCH
RIGHT RUNNING BOARD LAMP RIGHT RUNNING BOARD LAMP
RIGHT SIDE RAIL LAMP
RIGHT VANITY LAMP
UNIVERSAL GARAGE DOOR OPENER
W/ AUX A/C
W/ FULL OVERHEAD CONSOLE
W/ FULL OVERHEAD CONSOLE W/O FULL OVERHEAD CONSOLE
W/ MINI CONSOLE ONLY
W/O AUX A/C
WHT WIRE
WHT/RED WIRE
WIPER/ WASHER SYSTEM
XLT ONLY
Go to component -> Courtesy lamps circuit -> XLT ONLY
Wiring diagram xlt only (2 of 2)
ADJUST- ABLE PEDAL SWITCH
AIRBAG SLIDILNG CONTACT 4 WHEEL DRIVE MODE SWITCH
AIRBAG SLIDING CONTACT
ASHTRAY ILLUMINATION
BATTERY JUNCTION BOX
BLK WIRE
BLK/LT BLU WIRE
BLU WIRE
BRN WIRE
CENTRAL JUNCTION BOX
CIGAR LIGHTER
CLOCK
CLOCK NAVIGATION SYSTEM MODULE (NAVIGATOR)
DIMMER MODULE
DK BLU/WHT WIRE
DK GRN/ORG WIRE
ELECTRONIC AUTOMATIC TEMPERATURE CONTROL MODULE
EXPEDITION, NAVIGATOR
EXTERIOR LIGHTS CIRCUIT
FRONT BLOWER ILLUMI- NATION SWITCH
FRONT BLOWER ILLUMINATION SWITCH
FULL OVERHEAD CONSOLE OR XLT
FUSE 18
FUSE 6
HEAD OFF
HOT AT ALL TIMES
INSTRUMENT CLUSTER (6 BULBS)
LEFT FRONT POWER DOOR LOCK SWITCH
LEFT FRONT POWER WINDOW SWITCH LEFT REAR WINDOW SWITCH
LEFT REAR VENT WINDOW SWITCH
LT BLU WIRE
LT BLU/RED WIRE
MAIN LIGHT SWITCH
MINI OVERHEAD CONSOLE
NCA WIRE
OVERHEAD CONSOLE
PARK
PARKING AID DISABLE SWITCH NAV- IGATION CONTROL PANEL (NAV- IGATOR)
RADIO FUNCTION SELECTOR SWITCH
REAR BLOWER ILLUMI- NATION SWITCH
REAR BLOWER ILLUMINATION SWITCH
REAR INTE- GRATED CONTROL PANEL
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT POWER DOOR LOCK SWITCH
RIGHT REAR VENT WINDOW SWITCH
RIGHT REAR WINDOW SWITCH
ROOF OPENING PANEL SWITCH
STEERING COLUMN ASSEMBLY
TAN/WHT WIRE
W/FULL OVERHEAD CONSOLE W/O AUX A/C
XLT ONLY
Go to component -> Instrument illumination circuit -> XLT ONLY
