Ford Expedition I (1996-2002) rotation rate input Wiring diagram
This page shows the only wiring diagram for the component.rotation rate input, which is found in the car Ford Expedition I (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rotation rate input (1 of 1)
2 3 4 ROTATION RATE INPUT VEHICLE SIGNAL INPUT IGNITION
AIR SUSPENSION/ EVO STEERING MODULE (BEHIND CENTER OF DASH)
BLK WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BRN WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
ENGINE CONTROL SYSTEM
EVO ACT OUTPUT
EVO ACTUATOR (LEFT SIDE OF ENGINE COMPT)
FUSE 6
GENERIC ELECTRONIC MODULE
GROUND
GRY/BLK WIRE
GRY/YEL WIRE
HOT IN RUN
NCA WIRE
ORG/ WIRE
RED WIRE
RED/YEL WIRE
ROTATION RATE INPUT
SPEED CONTROL SERVO (LEFT SIDE OF ENGINE COMPARTMENT)
STEERING WHEEL ROTATION SENSOR (BEHIND STEERING WHEEL, IN DASH)
YEL WIRE
Go to component -> Electronic power steering circuit, with air suspension -> ROTATION RATE INPUT
