Ford Expedition I (1996-2002) power mirror switch wiring diagram
This page shows the only wiring diagram for the component.power mirror switch, which is found in the car Ford Expedition I (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
power mirror switch wiring diagram (1 of 1)
1999 ONLY
BLK WIRE
BLK/LT BLU WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DATA LINK CONNECTOR (DLC) (UNDER CENTER OF DASH)
DEFOGGER SYSTEM
DIRECT- TIONAL SWITCH
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/ORG WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DRIVER SEAT MODULE (UNDER DRIVER'S SEAT)
FUSE 4
GRY WIRE
GRY/RED WIRE
HORIZ
HORIZ MTR
HOT AT ALL TIMES
LEFT EXTERIOR REAR VIEW MIRROR
LEFT HEATED MIRROR
LEFT/RIGHT MIRROR SELECT SWITCH
LT BLU WIRE
LT BLU/RED WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
ORG/LT GRN WIRE
POWER MIRROR SWITCH
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT HEATED MIRROR
VERT
VERT MTR
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/VIO WIRE
YEL/BLK WIRE
YEL/LT BLU WIRE
YEL/RED WIRE
Go to component -> Memory mirrors circuit -> POWER MIRROR SWITCH
