Ford Expedition I (1996-2002) pnk reverse lights system Wiring diagram
This page shows the only wiring diagram for the component.pnk reverse lights system, which is found in the car Ford Expedition I (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk reverse lights system (1 of 1)
BLK WIRE
BLK/PNK WIRE
DIGITAL TRANSMISSION RANGE (DTR)
ELECTRONIC DAY/NIGHT MIRROR REVERSE SENSE
FUSE
GROUND
HOT IN RUN
HOT IN RUN CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) FUSE
LT BLU WIRE
PARKING AID MODULE
PNK REVERSE LIGHTS SYSTEM WIRE
PNK WIRE
POWER
SENSOR (LEFT SIDE OF TRANSMISSION)
WHT WIRE
Go to component -> Electronic day/night mirror circuit -> PNK REVERSE LIGHTS SYSTEM WIRE
