Ford Expedition I (1996-2002) off sta Wiring diagram
This page shows the only wiring diagram for the component.off sta, which is found in the car Ford Expedition I (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off sta (1 of 1)
BATTERY
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) FUSE 21
CHARGING CIRCUIT
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (LEFT SIDE OF TRANSMISSION)
DK BLU WIRE
FUSE 111
FUSE LINK A (12 GA- GRAY) (NEAR BATTERY)
FUSE LINK B (12 GA- GRAY) (NEAR BATTERY)
GRY WIRE
IGNITION SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
OFF STA
ORG/ WIRE
POWER DISTRIBUTION
RED WIRE
RUN WIRE
STARTER MOTOR (LOWER RIGHT SIDE OF ENGINE)
STARTER MOTOR RELAY (RIGHT REAR OF ENGINE COMPT)
TAN WIRE
VIO WIRE
Go to component -> Starting circuit -> OFF STA
