Ford Expedition I (1996-2002) left center sensor input Wiring diagram
This page shows the only wiring diagram for the component.left center sensor input, which is found in the car Ford Expedition I (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left center sensor input (1 of 1)
BATTERY JUNCTION BOX
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BRN/PNK WIRE
CENTRAL JUNCTION BOX
DATA LINK CONNECTOR
DIGITAL TRANS RANGE SENSOR MODULE (RAPS) REVERSE (ON TRANS)
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
DRIVER SEAT MODULE
ELECTRONIC DAY/NIGHT MIRROR
FUSE 6
GROUND
GRY WIRE
GRY/YEL WIRE
HOT IN RUN
INSTRUMENT ILLUMINATION
ISO 9141
LEFT CENTER PARKING AID SENSOR
LEFT CENTER SENSOR INPUT
LEFT OUTER PARKING AID SENSOR
LEFT OUTER SENSOR INPUT
LEFT REVERSING LAMP
LT BLU WIRE
LT BLU/WHT WIRE
ON/OFF SWITCH
ORG/ WIRE
PARKING AID DISABLE SWITCH (IN GLOVE BOX)
PARKING AID MODULE (RIGHT REAR OF VEHICLE)
PARKING AID SPEAKER
PNK WIRE
POWER
RED WIRE
REVERSE INPUT
RIGHT CENTER PARKING AID SENSOR
RIGHT CENTER SENSOR INPUT
RIGHT OUTER PARKING AID SENSOR
RIGHT OUTER SENSOR INPUT
RIGHT REVERSING LAMP
SENSOR GROUND
SENSOR POWER
SPEAKER
STATUS LED
TO MULTIPLEX COMMUNICATION NETWORK
VIO WIRE
VIO/ORG WIRE
W/MEMORY SEAT
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
YEL WIRE
Go to component -> Parking assistant circuit -> LEFT CENTER SENSOR INPUT
