Ford Expedition I (1996-2002) generic electronic module interior lamps system Wiring diagram
This page shows the only wiring diagram for the component.generic electronic module interior lamps system, which is found in the car Ford Expedition I (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram generic electronic module interior lamps system (1 of 1)
1000 OHMS
2900 OHMS
330 OHMS
ALL WHEEL DRIVE SYSTEM
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BATTERY SAVER RELAY
BLK WIRE
BRN WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FRONT WASHER PUMP CTRL
FRONT WASHER PUMP RELAY
FUSE 11
FUSE 12
FUSE 14
GENERIC ELECTRONIC MODULE (BEHIND LEFT SIDE OF DASH)
GENERIC ELECTRONIC MODULE INTERIOR LAMPS SYSTEM
HOT AT ALL TIMES
HOT IN ACC OR RUN
INTERVAL DELAY/WASH
LT BLU WIRE
LT GRN WIRE
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
ORG/ WIRE
PK LO
PNK WIRE
REAR WASHER PUMP CTRL
REAR WASHER PUMP RELAY
REAR WIPER DOWN RELAY
REAR WIPER HI/LO PARK SENSE
REAR WIPER MOTOR
REAR WIPER SWITCH
REAR WIPER UP RELAY
RED WIRE
SIGNAL RETURN
TAN WIRE
VIO WIRE
WASH
WASHER PUMP MOTOR (IN FLUID RESERVOIR)
WASHER SWITCH
WHT WIRE
YEL WIRE
Go to component -> Rear washer/wiper circuit -> GENERIC ELECTRONIC MODULE INTERIOR LAMPS SYSTEM
