Ford Excursion I (1999-2005) windshield wiper motor assembly Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper motor assembly, which is found in the car Ford Excursion I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper motor assembly (1 of 1)
BLK WIRE
BRN WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH)
FUSE 21
FUSE 48
HOT AT ALL TIMES
HOT IN RUN OR ACC
LT GRN WIRE
MULTI-FUNCTION SWITCH 1. WASH 2. OFF 3. VARIABLE INTERMITTENT 4. ON
SOLID STATE
VIO WIRE
WASHER PUMP RELAY
WHT WIRE
WINDSHIELD WASHER PUMP MOTOR (ON RIGHT SIDE OF ENGINE COMPT)
WINDSHIELD WASHER RELAY
WINDSHIELD WIPER MOTOR ASSEMBLY
WIPER RUN/PARK RELAY
Go to component -> Rear washer/wiper circuit -> WINDSHIELD WIPER MOTOR ASSEMBLY
