Ford Excursion I (1999-2005) w/ pwr seats wiring diagram
This page shows the only wiring diagram for the component.w/ pwr seats, which is found in the car Ford Excursion I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ pwr seats wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 GND
BLK WIRE
BLK/LT BLU WIRE
BRN WIRE
BRN/LT BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH)
DK GRN/VIO WIRE
DRIVER SIDE FRONT HEATED SEAT MODULE
DRIVER SIDE SEAT HEATER SWITCH
FUSE 109
FUSE 27
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
IND
LEFT FRONT SEAT BACK HEATER
LEFT FRONT SEAT CUSHION HEATER
LT BLU WIRE
LT BLU/PNK WIRE
ORG/ WIRE
PASSENGER SIDE FRONT HEATED SEAT MODULE
PASSENGER SIDE SEAT HEATER SWITCH
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT SEAT BACK HEATER
RIGHT FRONT SEAT CUSHION HEATER
SENS RET SENS FEED VOLTAGE HEATER FEED HEATER RET SW INPUT
VIO WIRE
VIO/LT BLU WIRE
W/ PWR SEATS
W/O PWR SEATS
YEL WIRE
YEL/LT BLU WIRE
