Ford Excursion I (1999-2005) speed ctrl set lamp Wiring diagram
This page shows the only wiring diagram for the component.speed ctrl set lamp, which is found in the car Ford Excursion I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed ctrl set lamp (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR (ON ACCELERATOR PEDAL SUPPORT)
BAROMETRIC ABSOLUTE PRESSURE (BAP) SENSOR (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH)
DK BLU/LT GRN WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/LT GRN WIRE
DK GRN/WHT WIRE
FROM PCM POWER RELAY (DIAGRAM 1 OF 4)
FUEL HEATER RELAY
FUEL PUMP RELAY
FUSE 105
FUSE 40
GLOW PLUGS LEFT VALVE COVER ASSEMBLY
GLOW PLUGS RIGHT VALVE COVER ASSEMBLY
GLW PLG 1
GLW PLG 2
GLW PLG 3
GLW PLG 4
GLW PLG 5
GLW PLG 6
GLW PLG 7
GLW PLG 8
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE LINK FUSE LINK I (12 GA
INSTRUMENT CLUSTER
LT BLU/BLK WIRE
LT BLU/ORG WIRE
LT BLU/RED WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (AT RIGHT SIDE OF FIREWALL)
NCA WIRE
ORG/LT BLU WIRE
ORG/YEL WIRE
PCM
PNK/BLK WIRE
PNK/LT GRN WIRE
POWER IN
RED WIRE
RED/LT BLU WIRE
RED/LT GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SPEED CTRL SET LAMP
VIO/ORG WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 6.0l diesel (2 of 5) -> SPEED CTRL SET LAMP
