Ford Excursion I (1999-2005) logic gnd blower speed control signal return Wiring diagram

A/C DEMAND SIG BLEND DOOR ACTUATOR BLEND DOOR ACTUATOR AIR BAG SLIDING CONTACT AMBIENT AIR TEMPERATURE SENSOR (ON LEFT FRONT OF ENGINE COMPT) AMBIENT TEMP BLEND DOOR SENSE + BLOW MOTOR RLY CONTROL BRN WIRE BRN/LT BLU WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) DIESEL DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK GRN/ORG (OR GRY/RED) WIRE DK GRN/ORG WIRE ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE (BEHIND CENTER OF DASH) FAN TEMP FAN SPEED (+) SPEED (-) (+) FUSE 28 FUSE 34 GASOLINE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN IGN IN CAR TEMP SENSOR SUNLOAD SENSOR SIG BLEND DOOR MONITOR IN-VEHICLE TEMPERATURE SENSOR (BEHIND LEFT SIDE OF DASH) LOGIC GND BLOWER SPEED CONTROL SIGNAL RETURN LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK/BLK WIRE PNK/ORG WIRE POWERTRAIN CONTROL MODULE (PCM) (ON LEFT SIDE OF FIREWALL) SIG RTN RED/LT GRN WIRE RED/WHT WIRE REMOTE SOLENOID ASSEMBLY REST REST REST SENSOR RETURN BLEND DOOR SIGNAL - SOLENOID ASSEMBLY SOLENOID ASSEMBLY SPEED CONTROL SERVO (IN RIGHT SIDE OF ENGINE COMPT) SIG RTN SPEED CONTROLLER STEERING WHEEL RADIO SWITCH TAN/WHT WIRE TEMP TEMPERATURE BLEND DOOR ACTUATOR (BEHIND RIGHT SIDE OF DASH) UBP DIAG VIO WIRE WHT WIRE WHT/LT BLU WIRE WHT/ORG WIRE WHT/VIO WIRE YEL/LT GRN WIRE YEL/RED WIRE
