Ford Excursion I (1999-2005) gnd vbatt Wiring diagram
This page shows the only wiring diagram for the component.gnd vbatt, which is found in the car Ford Excursion I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd vbatt (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 TX SIG IND
5 SPEED A/T
ANTI- THEFT IND
BLK WIRE
CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH)
DATA LINK CONNECTOR (DLC) (BEHIND LEFT SIDE OF DASH)
FUSE 34
FUSE 44
GND VBATT
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
LT BLU WIRE
LT BLU/BLK WIRE
NCA WIRE
ORG/RED WIRE
PASSIVE ANTI-THEFT TRANSCEIVER (BEHIND LEFT SIDE OF DASH, NEAR STEERING COLUMN)
PASSIVE ANTI-THEFT TRANSCEIVER MODULE (BEHIND LEFT CENTER OF DASH)
PNK/LT BLU WIRE
PNK/ORG WIRE
POWERTRAIN CONTROL MODULE (ON LEFT SIDE OF FIREWALL)
RED/YEL WIRE
RX SIG
SCP - SCP +
SCP+
STARTER RELAY
TAN/ORG WIRE
TAN/WHT WIRE
TX SIG
VBATT
VBATT RX SIG
WHT/LT GRN WIRE
Go to component -> Passive anti-theft circuit -> GND VBATT
