Ford Excursion I (1999-2005) cust acc tp sig a/c clutch input speed ctrl ind chassis gnd Wiring diagram

6 14 2 DATA LINK CONNECTOR (DLC) (BEHIND LEFT SIDE OF DASH) A/C SYSTEM A/T AUXILIARY POWERTRAIN CONTROL MODULE (APCM) (BEHIND LEFT SIDE OF DASH) AUXILIARY RELAY BOX 5 (AT LEFT REAR SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE PEDAL POSITION (BPP) SWITCH (BEHIND LEFT SIDE OF DASH, ABOVE BRAKE PEDAL) BRAKE PRESSURE SWITCH BRN/PNK WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) CLUTCH PEDAL POSITION (CPP) SWITCH (M/T) (ABOVE CLUTCH PEDAL) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM CUST ACC TP SIG A/C CLUTCH INPUT SPEED CTRL IND CHASSIS GND DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK GRN/LT GRN WIRE DK GRN/YEL WIRE FUSE 103 FUSE 20 FUSE 34 FUSE 22 FUSE 24 GRADE/LOAD SWITCH (A/T) GRY WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES HOT AT ALL TIMES CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) FUSE 116 HOT IN INJECTOR DRIVER MODULE POWER RELAY LOCK OFF LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE M/T M/T A/T MASS AIRFLOW (MAF) SENSOR NCA WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE OVERHEAD CONSOLE STARTING/CHARGING SYSTEM PARK BRAKE SWITCH ABS CONTROL (ON PARK MODULE BRAKE ASSEMBLY) PCM POWER DIODE PCM POWER RELAY PNK/BLK WIRE PNK/LT BLU WIRE PNK/ORG WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (ON LEFT FENDER, NEAR BATTERY) PWR GND PTO CTRL RED WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RUN WIRE STARTING/ CHARGING SYSTEM CRUISE CONTROL SYSTEM TACH OUTPUT A/C CLUTCH RLY DATA OUTPUT LINK START RLY CTRL FUEL PMP RLY TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/WHT (OR TAN/LT BLU) WIRE TAN/WHT WIRE TAN/YEL WIRE TO FUEL PUMP RELAY (DIAGRAM 2 OF 4) VIO WIRE WATER IN FUEL SENSOR (AT TOP RIGHT SIDE OF ENGINE) WHT RED/ WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/WHT WIRE
