Ford Excursion I (1999-2005) crankshaft position shield Wiring diagram
This page shows the only wiring diagram for the component.crankshaft position shield, which is found in the car Ford Excursion I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crankshaft position shield (1 of 1)
5.4L, 6.8L
5.4L, 6.8L, 7.3L
6.0L
7.3L
A/C CLUTCH SOLENOID
A/C COMPRESSOR CLUTCH DIODE
AIR FILTER SENSOR
AUTO A/C
BATTERY
BATTERY 2
BATTERY CHARGE TRAILER TOW RELAY STARTER RELAY
BLK WIRE
BRAKE FLUID LEVEL SWITCH
CRANKSHAFT POSITION SHIELD
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS (DRL) RELAY 1 (6.0L) A/C CLUTCH SOLENOID
DAYTIME RUNNING LAMPS (DRL) RELAY 2
DIESEL
ENGINE COMPARTMENT LAMP
FRONT BLOWER MOTOR SPEED CONTROLLER
FRONT HEATER BLOWER MOTOR RESISTOR
FUEL PUMP
HORN
LEFT FRONT FOG LAMP
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEADLAMP
LEFT TURN TRAILER TOW RELAY
LEFT TURN TRAILER TOW RELAY RIGHT TURN TRAILER TOW RELAY
LT BLU WIRE
MAN A/C
NCA WIRE
ORG/ WIRE
PARKING LAMP TRAILER TOW RELAY
PCM POWER DIODE
PCM POWER RELAY
PNK PNK PNK PNK PNK PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) WINDSHIELD WIPER MOTOR
RESTRAINTS CONTROL MODULE
REVERSING LAMP TRAILER TOW RELAY
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE LAMP
RIGHT HEADLAMP
RIGHT TURN TRAILER TOW RELAY
SPEED CONTROL SERVO
TRANSFER CASE HIGH TO LOW RELAY
TRANSFER CASE LOW TO HIGH RELAY
VACUUM PUMP MOTOR
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> CRANKSHAFT POSITION SHIELD
