Ford Excursion I (1999-2005) cooling fan speed sig Wiring diagrams

BRN/LT GRN WIRE BRN/PNK WIRE COOLING FAN SPEED SIG DK BLU WIRE ELECTRONIC FAN CLUTCH ELECTRONIC FAN CLUTCH CONTROL ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON TOP LEFT FRONT OF ENGINE) GRY/RED WIRE NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (ON LEFT SIDE OF FIREWALL) RED/ORG WIRE SIG RTN VREF YEL/BLK WIRE YEL/WHT WIRE

5.4L/6.8L 7.3L 6.0L 6.0L 8 16 A/C PRESS SW IN A/C PRESS SW IN A/C CLUTCH SOLENOID A/C COMPRESSOR CLUTCH DIODE A/C HIGH PRESSURE SWITCH (IN RIGHT SIDE OF ENGINE COMPT) 6.0L A/C PRESS SWITCH SIG RTN 18 69 PNK/ A/C CLUTCH RELAY WIRE BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLOWER MOTOR SWITCH BRN WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) COOLING FAN SPEED SIG DK BLU WIRE DUAL PRESSURE (6.0L) (AT FRONT OF ENGINE) ELECTRONIC FAN CLUTCH (6.0L) ELECTRONIC FAN CLUTCH CTRL EXC 6.0L EXCEPT 6.0L EXCEPT 6.0L 6.0L FRONT FUNCTION SELECTOR SWITCH ASSEMBLY FRONT HEATER BLOWER MOTOR RESISTOR (AT REAR OF ENGINE COMPT) FUSE 10 FUSE 107 FUSE 23 FUSE 25 FUSE 27 FUSE 28 GRY WIRE GRY/WHT WIRE HEATER BLOWER MOTOR (AT RIGHT REAR SIDE OF ENGINE COMPT) HIGH MED LOW HOT AT ALL TIMES HOT IN HOT IN RUN HOT IN START OR RUN ILLUMINATION LT BLU WIRE LT BLU/PNK WIRE LT GRN WIRE LT GRN/WHT WIRE MIX FLOOR DEFROST OFF MODE SWITCH VENT NORMAL MAX MODE SELECTOR SWITCH MIX FLOOR DEFROST NCA WIRE OFF MODE SWITCH VENT NORMAL MAX OR RUN ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (ON LEFT SIDE OF FIREWALL) REAR AIR CONDITIONING CIRCUIT (EXCURSION) RED WIRE RED/LT GRN WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE RUN WIRE SIG RTN SOLID STATE SWITCH TAN WIRE TAN/LT GRN WIRE TEMPERATURE BLEND DOOR ACTUATOR TEMPERATURE CONTROL POTENTIOMETER VACUUM PUMP MOTOR (DIESEL) (IN RIGHT SIDE OF ENGINE COMPT) VIO WIRE VREF WHT WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/LT GRN WIRE YEL/RED WIRE
