Ford Excursion I (1999-2005) blend dr pot rtn ignition ground Wiring diagram

BLEND DR POT RTN IGNITION GROUND BLEND POTENTIOMETER BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BLOWER MOTOR BLU WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) DEF FLOOR OFF MAX DK BLU WIRE DK BLU/WHT WIRE DK GRN/YEL WIRE EATC FRNT MODE POT RTN IGNITION GROUND FRONT AUXILIARY FUNCTION SELECTOR SWITCH ASSEMBLY FUSE 107 FUSE 108 FUSE 27 FUSE 28 GRY WIRE GRY/LT BLU WIRE HOT AT ALL TIMES HOT IN RUN IGNITION BLEND DR ACT POSIT SNS MODE ACT POSIT SNS LOW MED HIGH MED LOW LT BLU WIRE LT BLU/ORG WIRE LT BLU/PNK WIRE LT DK LT GRN WIRE LT PNK PNK WIRE MANUAL/ AUTO A/C CIRCUIT (EXCURSION) MED HIGH HIGH MIX MODE POTENTIOMETER NORMAL VENT FRONT FUNCTION SELECTOR SWITCH ASSEMBLY (BEHIND LEFT SIDE OF DASH) OFF OFF LOW MED LOW ORG/ WIRE ORG/RED WIRE PNK PNK WIRE PNK WIRE PNK/LT GRN WIRE PNK/WHT WIRE REAR A/C CONTROL MODULE (IN RIGHT REAR CORNER OF VEHICLE, AFTER "C" PILLAR) REAR A/C CTRL SIG MODE ACT POSIT SIG REAR A/C CTRL SIG TEMP BLEND DR ACT FEED REAR AUXILIARY FUNCTION SELECTOR SWITCH ASSEMBLY REAR BLEND DOOR ACTUATOR (IN RIGHT REAR CORNER OF VEHICLE, AFTER "C" PILLAR) REAR BLOWER MOTOR (IN RIGHT REAR CORNER OF VEHICLE, AFTER "C" PILLAR) REAR MODE DOOR ACTUATOR RED WIRE RELAY VIO WIRE W/O EATC WHT WIRE WHT/VIO WIRE YEL WIRE YEL/WHT WIRE
