Ford Excursion I (1999-2005) auxiliary air conditioning circuit Wiring diagram

6.0L 7.3L POWERTRAIN CONTROL MODULE (PCM) (ON LEFT SIDE OF FIREWALL) 5.4L/6.8L 6.0L A/C CLUTCH RELAY A/C CLUTCH SOLENOID A/C COMPRESSOR CLUTCH DIODE A/C HIGH PRESSURE SWITCH (IN RIGHT SIDE OF ENGINE COMPT) A/C PRESS SWITCH SIG 18 69 PNK/ A/C CLUTCH RELAY WIRE AUXILIARY AIR CONDITIONING CIRCUIT BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BRN/ORG WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) DATA LINK CONNECTOR (DLC) (BEHIND LEFT SIDE OF DASH) DK BLU/ORG WIRE DUAL PRESSURE (6.0L) (AT FRONT OF ENGINE) EXC 6.0L (AT LEFT SIDE OF ENG COMPT) EXCEPT 6.0L FRONT BLOWER MOTOR SPEED CONTROLLER (AT RIGHT REAR SIDE OF ENGINE COMPT) FUSE 10 FUSE 107 FUSE 23 FUSE 27 GRY WIRE GRY/WHT WIRE HEATER BLOWER MOTOR (AT RIGHT REAR SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN LT BLU/PNK WIRE LT GRN WIRE LT GRN/WHT WIRE NCA WIRE OR RUN ORG/ WIRE ORG/BLK WIRE PNK/ORG WIRE PNK/YEL WIRE RED WIRE RED/YEL WIRE RUN WIRE SUNLOAD SENSOR (ON TOP CENTER OF DASH) SWITCH TAN WIRE TAN/LT GRN WIRE VACUUM PUMP MOTOR (6.0L) (IN RIGHT SIDE OF ENGINE COMPARTMENT) VIO WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE
