Ford Excursion I (1999-2005) (at left side of engine Wiring diagrams

This page contains all the electrical diagrams for the component. (at left side of engine, in which he is found in the car Ford Excursion I (1999-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

(at left side of engine wiring diagram (1 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (1 of 8)

5.4L, 6.8L 5.4L, 6.8L, 7.3L 6.0L 6.0L EXCEPT 6.0L 7.3L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) CHARGE DK BLU WIRE FUSE 116 FUSE 45 FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK H FUSIBLE LINK I GENERATOR HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE POWER DISTRIBUTION SYSTEM RED WIRE RUN WIRE STARTER MOTOR WHT WIRE YEL WIRE YEL/WHT (OR RED) WIRE

Go to component -> 5.4l, charging circuit, without dual generators -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (2 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (2 of 8)

6.0L 7.3L 7.3L 6.0L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) CHARGE DK BLU/ORG WIRE FUSE 116 FUSE 45 FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK H FUSIBLE LINK I FUSIBLE LINK J GENERATOR HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT GRN/RED (OR VIO) WIRE LT GRN/RED WIRE ORG/ WIRE ORG/LT BLU WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (ON LEFT SIDE OF FIREWALL) RED WIRE RED/LT GRN WIRE RED/YEL WIRE RUN WIRE SECONDARY GENERATOR STARTER MOTOR WHT WIRE WHT/YEL WIRE YEL WIRE YEL/WHT (OR RED) WIRE YEL/WHT WIRE

Go to component -> 6.0l diesel, charging circuit, with dual generators -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (3 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (3 of 8)

5.4L, 6.8L 5.4L, 6.8L, 7.3L 6.0L 6.0L EXCEPT 6.0L 7.3L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) CHARGE DK BLU WIRE FUSE 116 FUSE 45 FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK H FUSIBLE LINK I GENERATOR HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE POWER DISTRIBUTION SYSTEM RED WIRE RUN WIRE STARTER MOTOR WHT WIRE YEL WIRE YEL/WHT (OR RED) WIRE

Go to component -> 6.0l diesel, charging circuit, without dual generators -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (4 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (4 of 8)

5.4L, 6.8L 5.4L, 6.8L, 7.3L 6.0L 6.0L EXCEPT 6.0L 7.3L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) CHARGE DK BLU WIRE FUSE 116 FUSE 45 FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK H FUSIBLE LINK I GENERATOR HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE POWER DISTRIBUTION SYSTEM RED WIRE RUN WIRE STARTER MOTOR WHT WIRE YEL WIRE YEL/WHT (OR RED) WIRE

Go to component -> 6.8l, charging circuit, without dual generators -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (5 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (5 of 8)

6.0L 7.3L 7.3L 6.0L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) CHARGE DK BLU/ORG WIRE FUSE 116 FUSE 45 FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK H FUSIBLE LINK I FUSIBLE LINK J GENERATOR HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT GRN/RED (OR VIO) WIRE LT GRN/RED WIRE ORG/ WIRE ORG/LT BLU WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (ON LEFT SIDE OF FIREWALL) RED WIRE RED/LT GRN WIRE RED/YEL WIRE RUN WIRE SECONDARY GENERATOR STARTER MOTOR WHT WIRE WHT/YEL WIRE YEL WIRE YEL/WHT (OR RED) WIRE YEL/WHT WIRE

Go to component -> 7.3l di turbo diesel, charging circuit, with dual generators -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (6 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (6 of 8)

5.4L, 6.8L 5.4L, 6.8L, 7.3L 6.0L 6.0L EXCEPT 6.0L 7.3L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LOWER LEFT SIDE OF DASH) CHARGE DK BLU WIRE FUSE 116 FUSE 45 FUSIBLE LINK C FUSIBLE LINK D FUSIBLE LINK E FUSIBLE LINK H FUSIBLE LINK I GENERATOR HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT CLUSTER LOCK OFF LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE POWER DISTRIBUTION SYSTEM RED WIRE RUN WIRE STARTER MOTOR WHT WIRE YEL WIRE YEL/WHT (OR RED) WIRE

Go to component -> 7.3l di turbo diesel, charging circuit, without dual generators -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (7 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (7 of 8)

6.0L BATTERY BATTERY 2 (DIESEL) BLK WIRE CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) CLUTCH PEDAL POSITION SWITCH (BEHIND LEFT SIDE OF DASH, ABOVE CLUTCH PEDAL) DIGITAL TRANSMISSION RANGE (DTR) SENSOR (ON LEFT SIDE OF TRANSMISSION) DK GRN WIRE EXC 6.0L FUSE 103 FUSE 110 FUSE 113 FUSE 31 FUSIBLE LINK A FUSIBLE LINK B JUNCTION BLOCK LOCK OFF LT BLU WIRE LT GRN WIRE M/T NCA WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RUN WIRE STA IGNITION SWITCH STARTER MOTOR STARTER RELAY TAN WIRE TAN/RED WIRE VIO WIRE WHT WIRE YEL WIRE

Go to component -> Starting circuit, 4 speed a/t, m/t & 4 speed a/t -> (AT LEFT SIDE OF ENGINE

(at left side of engine wiring diagram (8 of 8)

Ford Excursion I (1999-2005) (at left side of engine wiring diagram (8 of 8)

BATTERY BATTERY 2 (DIESEL) BLK WIRE BLK/WHT WIRE CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) DK GRN WIRE FUSE 110 FUSE 113 FUSE 31 FUSIBLE LINK A FUSIBLE LINK B JUNCTION BLOCK LOCK OFF LT BLU WIRE LT BLU/YEL WIRE LT GRN WIRE NCA WIRE PNK WIRE PNK/WHT WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (ON LEFT SIDE OF FIREWALL) RED WIRE RUN WIRE STA IGNITION SWITCH STARTER MOTOR STARTER RELAY TRANSMISSION TRANSMISSION RANGE SENSOR TRANSMISSIONS SYSTEM VIO WIRE WHT WIRE YEL WIRE

Go to component -> Starting circuit, 5 speed a/t -> (AT LEFT SIDE OF ENGINE
